YEJ Series 3 phase Electro Magnetic Brake Motors

Product name：YEJ Series 3 phase Electro Magnetic Brake Motors

Item：YEJ series

Details：

Product Description

YEJ Series 3phase Electro Magnetic Brake Motors

•　Features of fast stop, accurate positioning, frequent starting, back and forth running and prevent sliding.
•　Widely used in lifting machinery, package machinery, transportation machinery, food and printing machinery, metallurgy, woodworking, building and forging machinery and a variety of automatic production line.
•　Special data requirements can be satisfied.

Technical Data

Output Range: 0.55KW~450KW
Voltage: 415V/380V/660V/as required
Frequency: 50Hz/60Hz/as required
No. of Poles: 2, 4, 6, 8, 10, etc
Speed: 450rpm~3000rpm
Brake way: non-excitation brake (power-off brake)
Protection class: IP44 (brake mechanical part IP23)
Duty type: S1 (continuous)
Cooling method: IC0141
Insulation class: B
Connection: Y/D
Mounting styles: B3/B5/B35/V1, etc.
Brake way: non-excitation brake (power-off brake)

Parameters

Product Model	Rated Output (kw)	Speed (at full load) (r/min)	Product Model	Rated Output (kw)	Speed (at full load) (r/min)
YEJ801-2	0.75	2825	YEJ160L-4	15	1460
YEJ802-2	1.1	2825	YEJ180M-4	18.5	1470
YEJ90S-2	1.5	2840	YEJ180L-4	22	1470
YEJ90L-2	2.2	2840	YEJ200L-4	30	1470
YEJ100L-2	3.0	2880	YEJ225M-4	45	1480
YEJ112M-2	4.0	2890	YEJ90S-6	0.75	910
YEJ132S1-2	5.5	2900	YEJ90L-6	1.1	910
YEJ132S2-2	7.5	2900	YEJ100L-6	1.5	940
YEJ160M1-2	11	2930	YEJ112M-6	2.2	940
YEJ160M2-2	15	2930	YEJ132S-6	3	960
YEJ160L-2	18.5	2930	YEJ132M1-6	4.0	960
YEJ180M-2	22	2940	YEJ132M2-6	5.5	960
YEJ200L1-2	30	2950	YEJ160M-6	7.5	970
YEJ200L2-2	37	2950	YEJ160L-6	11	970
YEJ225M-2	45	2970	YEJ180L-6	15	970
YEJ801-4	0.55	1390	YEJ200L1-6	18.5	970
YEJ802-4	0.75	1390	YEJ200L2-6	22	970
YEJ80S-4	1.1	1400	YEJ225M-6	30	980
YEJ90L-4	1.5	1400	YEJ132S-8	2.2	710
YEJ100L1-4	2.2	1420	YEJ160M1-8	4.0	720
YEJ100L2-4	3.0	1420	YEJ160M2-8	5.5	720
YEJ112M-4	4.0	1440	YEJ160L-8	7.5	720
YEJ132S-4	5.5	1440	YEJ180L-8	11	730
YEJ132M-4	7.5	1440	YEJ225S-8	18.5	730
YEJ160M-4	11	1460	YEJ225M-8	22	730
